30mm width key type friction ring

key type  differential air shaft:

1. The low tension slip shaft is based on the principle of air compression, so that the device is inflated inside the shaft to cause the expansion of the top block, and the two air intakes drive each torque machine

The group expands outwards and sets each torque according to the amount of inflation pressure, which is suitable for PE elastic film materials.

2. According to customer needs, professional evaluation and design and manufacture, production of special specifications and special tension, special surface treatment.
3. All kinds of special environment (dust-free, corrosive, high temperature environment) can be applied.Key type Air differential shaft(friction rings)3”outer diameter:φ75 Expand diameter:φ78mm

   1)Applicable tube ID:φ76±0.2mm

   2)Inside diameter(ID):φ50mm

   3)Standard width:10、15、20、30、37mm,other sizes can made by request.

   6’’outer diameter:φ150 Expand diameter:φ156mm

   1)Applicable tube ID:φ152.4±0.2mm

   2)Inside diameter(ID):φ60mm

   3)Standard width:50mm,other size can made by request.

   Styles	Sizes(OD*ID*W)
   Ball type	75*60*25mm
   Ball type	75*60*30mm
   Key type	75*50*10mm
   Key type	75*50*15mm
   Key type	75*50*20mm
   Key type	75*50*30mm
   Key type	75*50*37mm
   Key type	75*55*50mm
   Key type	151*60*35mm
